Quick Details

  • Condition: New
  • CNC or Not: CNC
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: Multitech
  • Model Number: F2-9
  • Voltage: AC380V/50HZ
  • Power(W): 6.0KW&4.5KW
  • Dimension(L*W*H): 3400*1950*2050mm
  • Weight: 2300KG
  • Certification: CE ISO
  • Warranty: 2 Years
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Product name: Factory price ATC CNC wood router machine 1325 / CNC router
  • Working area: 1300mm*2500*200mm
  • Spindle: Air Cooling Spindle
  • Spindle power: 6.0KW HSD spindle, 4.5KW Chinese brand spindle
  • Motor: Japan Yaskawa Servo Motor
  • Software: Original Artcam
  • Driving system: YASKAWA Servo System
  • Inverter: Delta Inverter
  • Control system: Syntec
  • Working voltage: AC380V/50Hz/3PH

Packaging & Delivery

Packaging Details: Standard plywood case
Delivery Detail: 10Working days

Factory price ATC CNC wood router machine 1325 / CNC router

Application of Factory price ATC CNC wood router machine 1325 / CNC router:

Woodworking industry:

cabinet, kitchen wall cupboard, paint doors, screens, window processing technology, shoe polisher, game cabinets and panels, mahjong table, computer assisted processing tables and panel furniture products.

Advertising industry:

advertising signs, sign making, acrylic cutting, plastic molding, a variety of advertising and decorative products.

Mold industry:

carving copper, aluminum, iron and other metal molds, as well as artificial marble, sand, plastic board, PVC pipe, wood and other non-metallic mold.

Other industries:

various large relief carving, shadow carving, widely used in craft gift industry.

Parameter of Factory price ATC CNC wood router machine 1325 / CNC router:

Model

ITM1325

Work dimensions

1300×2500mm

Z-axis working area

200mm

X/Y/Z movement

Gear transmission and ball screw

Guide linear

20 square rail/Taiwan

Cut thickness of material

0-10cm

Max.Speed

6000mm/min

Working speed

0-4000mm/min

Machining pass

5mm

Mechanical precision

0.015mm

Software

Type3,Artcut,Artcam software

Power source

380V 3 phase 60HZ

Driver type

Yaskawa Servo motor

Spindle power

6.0KW HSD spindle and 4.5KW Chinese brand spindle,one boring head

Spindle speed

0-18000rpm

Tool diameter

1-12.7mm

Collet

Collet ER20 12mm, 12.7mm, 6mm, and 3.175mm

Control system

Syntec

Command

HPGL.G code,u00,mmg,plt



Detailed parts of Factory price ATC CNC wood router machine 1325 / CNC router:



 Samples of Factory price ATC CNC wood router machine 1325 / CNC router:

Our service

During sale:

We would deal with all the production and shipping affairs,after everything is ready,we would tell you everything goes well here;

After sale:

We would provide English Version working manual.

 If you have any questions during using and maintaining,our engineers who could speak very good english would answer you online or by calls.

 Machine warranty is two years.So if your machine has any unintentional damages,we would provide parts for free.

 If your machine has big problems if by any chance,our engineers would arrive there to debug and fix.

 Could be remote control if needed.

 24 hours life time after sale service.

Guaranty

1.Twoyearsquality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge when if there is any problem during the warranty period.

2.Lifetime maintenance free of charge.

3.Free training course at our plant.

4.We will provide the consumable parts at an agency price when you need replacement.

5.24 hours on line service each day, free technical support.

6.Machine has been adjusted before delivery.

Why ITECH CNC?

1.We provide you a solution and not just a machine

2.Well configured machine using hardware that makes the machine efficient, accurate, and reliable.

3.Feel Confident when buy from a CN company that has expert staffs with over 10 years of CNC building experience.

4.Get the support that you deserve from our confident well trained staff members.

5.ITECH prides itself in having the patience and the ability to provide knowledge and service.

Payment items

1.30% deposit, 70% by T/T against B/L copy;

2.Escrow of Alibaba (third party payment terms)

3. by L/C(total sum needs up to 10,000$)

Company Information

Packaging and Shipping

The advantages of Plywood Case Package:
1.plywood case, its compressive strength and bearing quality is better, is the market ofchoice for the goods of high-weight packaging;

Secondly , the board area is big, the soil structure is good,and operational process is simple,So its is better in leak proof ness and waterproof;

Thirdly , when importing the plywood case is with fumigation-free ,

theprocedure is simple.
2.The normal package is standard plywood packages.(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Certificate
Customers show
Exhibition
FAQ

Q1: How can I get the best machine for me?
Just tell me your work,we can according to your needs recommend the suitable one.

Q2: This is the first time I use this kind of machine, is it easy to operate?
The PDF introduction and sample video will be send to you with the machine,it's in detail ,if you still confused with some operate ,we can make a  Specialized teaching video for you.

Q3: If the machine has problem in my place, how could I do?
We offer remote assistance in 24 hours ,ensure can solve your problem in time .Change damage parts for free during warranty.

Q4: This model is not suitable for me, do you have more models available?
Yes, we have much models about cnc machine ,and we have our own factory also can make Custom models if you need with good price.

Q5: When i got this machine, but i did not know how to use it.What should i do?
 We will send video and english manual with the machine.If you still have some doubts, we can talk by telephone or skype.


 Q6:  If some problems happend to this machine during warranty period,what should i do?
We will supply free parts in machine warranty period if machine have some problem.While we also supply free after-service forever,so any doubts,just us know,we will give you solutions in 30 minuts.

Customers' good feedback



If you have a need on our products, just please feel free to contact me without hesitation.
