Quick Details

  • Application: Laser Cutting
  • Condition: New
  • Laser Type: Fiber Laser
  • Applicable Material: Metal
  • Cutting Thickness: 0-8mm
  • Cutting Area: 1300*2500mm
  • Cutting Speed: 600mm/min
  • CNC or Not: Yes
  • Cooling Mode: Water Cooling
  • Control Software: Cypcut6.3
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: Multitech
  • Model Number: ITJF1325
  • Certification: CE
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Model: ITJF1325
  • power type: fiber 500w
  • generator brand: Fiber Raycus/ IPG
  • controlling sys: Cypone
  • motor: servo motor
  • color: red and black
  • ball screw: Taiwan PMI

Packaging & Delivery

Packaging Details standard wooden case
Delivery Time 20 days

 Jinan facotry new finished fiber laser cutting machine price for metal cutting

Fiber laser cutting machine used for metal cutting



Applicable Materials



Fiber laser cutting machine is suitable for cutting stainless steel, carbon steel, mild steel, alloy steel, galvanized steel, silicon steel, spring steel, titanium sheet, galvanized sheet, iron sheet, inox sheet, aluminum, copper, brass and other metal sheet, metal plate, metal pipe and tube, etc.



Applicable Industries



Fiber laser cutting machine is applied to machinery parts, electrics, sheet metal fabrication, electrical cabinet, kitchenware, elevator panel, hardware tools, metal enclosure, advertising sign letters, lighting lamps, metal crafts, decoration, jewelry, medical instruments, automotive parts and other metal cutting fields.



The advantage is as follows:



Fiber Laser Cutting Machine integrates optical, mechanical and electrical in one, which adopts laser technology, computer control technology and high-performance CNC laser power system to process all kinds of metal sheet at high speed, high accurate, high efficiently cutting. Its products have smooth edge, small kerf width and little heat effect.

@ Better Performance, More Rigid and Durable Construction

A. Top quality components

B. Integrated circuit (professional circuit board)

C. Rigid machine tool and mass loading working

@ High Efficiently

A. Travelling speed increases utmost

B. Cutting software functions improved

C. Nesting software optimized cutting patch (can directly read CAD)

@ More Safe and Save Labor

A. Machine structure and electric circuit design and assembly conform with CE and FDA

B. Assistant loading system and wireless remote control handle

C. Lubrication system

@ More Optimized Technique

A. Different laser cutting heads and optimized nozzle

B. Three gas source and dual-pressure gas route

C. Strong software support

@ Higher Precision

A. Fully closed loop controlling system

B. Cutting compensation

C. Top accuracy testing device

2.Fiber Laser cutting machine parameters



ModelITJF1325ITJF1530ITJF2040
Working Area2500X1300mm3000X1500mm4000x2000mm
Laser TypeRaycus Fiber laser generator
Laser Power500W
Laser Wavelength1080 nm
Beam Quality<1.2mrad
Positioning Accuracy≤ ±0.03mm/m
Re-positioning Accuracy≤±0.02mm/m
Max Cutting Speed200mm/s(depending on material and thickness)
Power Supply Rated Voltage3-phase 380V/50Hz
X-axis Stroke2500mm3000mm4000mm
Y-axis Stroke1300mm1500mm2000mm
Z-axis Stroke120mm
Working TableRack working platform
Control SystemCypcut CNC control system
Location SystemRed dot indicator
Water Cooling SystemConstant temperature water chiller
Machine Weight2000-8000kg
Machine Dimension3500x1800x1600mm4300x2500x1600mm5000X2900X1600mm
RemarkAutomatic exchange worktable, cover(option)



  3 Machine suitable material & samples



More machine details



 Laser cutting machine price service

- 2 years

- provide technical services to the door  (We have professional engineers to offer machine installation commissioning and maintenance)

- replace all parts for free during the warranty period(no human damage)
- 24 hours technology online support (skype,whatsapp,viber,wechat,QQ)
- 24 hours service phone NO.:86-531-82367851
